BEONDT 300KG Lifting drone Transport drone Logistics drone

The 300 kg lifting drone is mainly used in emergency rescue and industrial transportation. It has multi-scenario adaptability and high load-bearing capacity. The following are the specific technical features:

Core performance

‌Maximum load‌: 300 kg, can carry ICU equipment, folding stretchers, mechanical arms and other medical equipment, or transport materials such as building materials and ore samples. ‌ ‌

Multi-scenario adaptability

‌Complex terrain‌: Supports mountainous, urban canyon, disaster ruins and other scenes, equipped with Beidou navigation and binocular vision system to achieve millimeter-level obstacle avoidance. ‌

‌Extreme weather‌: Protection level IP55, operating temperature range -20°C to 45°C, support rainstorm, dust and other environmental operations. ‌

Power and safety

‌Power system‌: Adopt hybrid power (fuel + electric) or high energy density battery, combined with lightweight composite fuselage, to solve the contradiction between load and endurance. ‌

‌Redundant design‌: Support 7 motor power redundancy to ensure safe flight in case of failure; dual-machine joint lifting technology can improve transportation efficiency and stability. ‌

Application Cases

‌Emergency Transportation‌: Successfully transported a full set of ICU equipment and two medical staff to the disaster site in a 2025 actual combat exercise. ‌

‌Industrial Transportation‌: Carried 50 kg of equipment to complete the maintenance of transmission towers during power inspections, increasing efficiency by 8 times compared to manual labor; Mining transportation shortened the geological exploration cycle by 40%.

Technical Parameters

Unfold the wheelbase: 5070mm

Motor stator size 1671*60.6mm

Propeler size: 1620mm

Fuselage unfolded dimension5970*5970*880mm

Fuselage folded dimensions3650-3650*880mm

Rated load: 250kg

Maximum load: ≤300kg

Maximum take-off weight: 620kg

Bare metal self-weight: 180kg

Battery weight: 140kg

Flight altitude: 1-2km

Maximum flight speed: 13m/s

Flight distance: 1-2km

Battery capacity: 18s 44000mAh

Number of batteries: 8

Battery weight: 17.5kg

Battery materials: high-rate lithium battery

Charging time: 30-40 minutes

Operating voltage: 66v

Charger power: 3000*8

Full load power: 88000w

Recommended ambient temperature: 15~35℃

Propeller material: Carbon

Fuselage material: Carbon fiber /aluminum alloy

Payload (300kg) endurance: 10 minutes

Payload (250kg) endurance: 12 minutes

No-load (200kg) endurance: 14 minutes

Number of camera axes: 2 axes

Camera zoom factor: 10 times

Camera resolution: 1080p 25fps

Remote control screen resolution: 1080p

Full load power: 880C0wresolution

Positioning system: GPS+dual-band RTK

Positioning accuracy: 10-20cm
